Yale Induro Mortice Lock 30MM / 2POINT
$143.05- Quantity: 0
Yale Induro Mortice Lock 30MM / 2POINT
Yale Induro Mortice LockThe Induro mortice lock offers a new and improved locking system with enhanced furniture options available. When deadlocked, the Induro 2-Point provides increased security with two points of locking. Made specifically for the New Zealand environment, this is an ideal locking solution.
Designed to be used in conjunction with the Verona and Palladium furniture ranges.
Features
- Features 2 points of locking from the latch and deadbolt
- The handing of the lockset is adjusted by reversing the orientation of the latch bolt
- 30mm backset
- 85mm pitch
- Preset 24mm throw on deadbolt can be set to 13mm throw with a screwdriver
- Stainless steel forend plate
- Adjustable latch projection
- Latch wear insert included
- Achieves Australian Standards AS4145: 2008 (Part 2) Security Level S7 and Durability Level D7
- Accepts Euro style cylinders
- New Zealand made
Before fixing the lock into the stile, select the correct deadbolt throw. To restrict the throw to 13mm select S, to restrict the throw to 24mm select L. Ensure the arrow is pointing to the desired throw application.
Note: When lock has 13mm projection selected the key must be rotated once deadlock. When lock has 24mm projection selected the key must be rotated twice to deadlock
